VIKING T-BAR

FEATURES

Comfort Adjustments

1. FORE and AFT Seat Adjustment (B)
Seat moves fore and aft to suit short or long-legged
drivers.
2. BACK-REST (C)
Back cushion has three positions to accommodate
driver preference and comfort.

3. WEIGHT ADJUSTER LEVER (A)
Seat adjusts to driver’s exact weight from 130 to 275 ,X‘
pounds by simple ratchet lever. For the Smoothest Truck Ride Ever —
Adjust your Viking T-Bar as follows:
4. RIDE LEVEL INDICATOR (D)
The indicator, located inside the left frame upright Back Cushion Angle and Fore and Aft
(see illustration), provides POSITIVE assurance position as desired.
that the seat is properly adjusted for the driver’s Weight Adjustment — For proper ride and
weight. If there is too much preload, the indicator comfort — adjust to each drivers weight
will be forward of the upright (1). If insufficient before making the day’s run.
preload, it will remain behind (2).
Ratchet adjuster makes it easy and RIDE
Adjust preload (step 3 above) in static position LEVEL INDICATOR shows when
until indicator is even with edge (3). adjustment is complete.

OPTIONAL EQUIPMENT
Space Requirements
Measure distances from old cushion
contours to steering wheel and place EXTRA DUTY SHOCK ABSORBER
— For exceptionally severe
operating conditions — off
highway or over rough
terrain — gravel or dump
truck, concrete mixers,
earth moving or similar
equipment. This option
can be used if seat to
floor clearance is 2 ¥2" or
more. See your dealer for
further information.
ARM REST — Easily
attached to side panel
assembly. Folds up
out of the way
when not in use.
SAFETY BELT KITS
—Can be easily installed as shown in illus­
tration. 30847-801 Lap Kit; 30848-801
Floor Kit.
