LIST OF FIGURES

Figure No. Title Page

1. Force Notation .................................. 14
2. General Arrangement - Aerodynamic Fairing 15
Typical Aerodynamic Fairing & Spoiler Installation 16
Backlight Configurations Tested 17
5. Underbody Simulation . 18
Comparison of 1968 and Proposed 1970 Race Configuration . . 19
Effect of Aerodynamic Fairing on Standard Car 24
8. Aerodynamic Effect of Aerodynamic Fairing Mounting
Attitude .................................................
9. Aerodynamic Effect of Front Spoiler Position . ...................... co <1
10. Aerodynamic Effect of Front Spoiler Thickness C O
11. Aerodynamic Effect of Front Spoiler Height Above Ground. . . 00
12. Aerodynamic Effect of Backlight Configuration C J 1 O

LIST OF TABLES

Table No. Title Page

1. Spoiler Identification 13

4
